3M Industrial Camera Cable Assemblies for Machine Vision

This is the future and the present in factory automation: functions like presence inspection, defect detection, measurement and more must be highly responsive in real time. Advanced industrial camera and sensor systems must capture increasingly complex information and deliver it with greater clarity. More than ever, machine vision depends on the deep expertise required to connect it all together.

You can improve the performance, robustness and reliability of your machine vision equipment – often at lower system costs – with cables, connectors and cable assemblies from 3M.

Our broad range of machine vision solutions is backed by decades of expertise in signal transmission, as well as electrical and mechanical cable design and technology. And our global presence provides the cable solutions you need are always within reach.

Our solutions

3M machine vision solutions cover three major industry standards for high speed/high density I/O applications.

USB3 Vision

3M offers a higher functional cable length than any other known USB3 connector solution – more than 10 meters for stationary cables (depending on system requirements) and up to 7 meters for cables tested to repetitive motion. We also provide cables drag chain tested from 10 million to greater than 100 million cycles.

Featured products:

3M™ USB3 Vision Industrial Camera Cable Assembly, 1U30G Series

3M™ USB3 Vision Industrial Camera Cable Assembly, 1U30E Series

3M™ USB3 Vision Industrial Camera Cable Assembly, 1U30A Series

3M™ USB3 Vision Industrial Camera Cable Assembly, 1U30S Series
Camera Link

3M offers a higher functional cable length than any other known USB3 connector solution – more than 10 meters for stationary cables (depending on system requirements) and up to 7 meters for cables tested to repetitive motion. We also provide cables drag chain tested from 10 million to greater than 100 million cycles.

Featured products:

3M™ Camera Link Industrial Camera Cable Assembly, MDR, 14x26 Series

3M™ Camera Link Industrial Camera Cable Assembly, MDR, 1WL26 Series

3M™ Camera Link Industrial Camera Cable Assembly, MDR/SDR, 1Mx26-x5xx Series

3M™ Camera Link Industrial Camera Cable Assembly, MDR/SDR, 1Mx26-xFxx Series

3M™ Camera Link Industrial Camera Cable Assembly, SDR, 1Sx26-x1xx Series
CoaXPress

The CoaXPress interface is excellent for longer transmission distance, durable cable flex life and high-bandwidth applications. 3M offers two types of cables for a range of requirements to meet the CoaXPress 2.0 standard.

Featured products:

3M™ CoaXPress Industrial Camera Cable Assembly 1CXx-xx-OG Series

3M™ CoaXPress Industrial Camera Cable Assembly 1CXx-xx-OS Series

Table comparing bandwidth, cable length, connections, architecture, additional hardware, triggering, easiness of integration, and cost for USB3 Vision, Camera Link and CoaXPress

Resources

White paper: - Achieving more effective machine vision interfaces

Download White paper (PDF, 155 KB)
Brochure - 3M cable assemblies for USB3 Vision

Download Brochure (PDF, 529 KB)
3M Selection Guide - MDR/SDR connectors

Download 3M Selection Guide (PDF, 557 KB)
3M Industrial Camera Cable Assemblies flyer

Download Fyler (PDF, 763 KB)
Brochure - 3M cable assemblies for CoaXPress

Download Brochure (PDF, 1.43 MB)
