Industrial and Manufacturing
Woman in a blue work outfit looking at a machine and taking notes.
Advanced technology for protecting and enhancing your electronic display

3M films for enhancement and protection of industrial displays

Whether you’re seeking a solution that can help protect displays from impacts, scratches, glare, solar loading or a solution that that will enhance the visibility of your display content, 3M has you covered. Have questions or not sure what product you need for your individual application? Our dedicated support team is here to provide specifications and application support.

Films for display enhancement in industrial applications

Display enhancement films

Display enhancement films

3M™ Brightness Enhancement Film (BEF) and 3M™ Dual Brightness Enhancement Film (DBEF) are recycling, light management films that are used to increase the brightness of backlights used in liquid crystal displays (LCD). The brightness increase can be the primary goal or it can be translated to power savings or thermal management. 3M™ Enhanced Specular Reflector (ESR) can be used to increase the overall efficiency of the backlight.

  • Large display with a brightly colored image on the screen.

    • 3M™ Dual Brightness Enhancement Film II (DBEF II)

      3M™ DBEF II is a thin, multi-layer reflective polariser. It features two diffuse surfaces to provide brightness enhancement and high visual quality. 3M™ DBEF II can improve display efficiency, uniformity and defect hiding, and has the ability to prevent wet-out against smooth surfaces. 3M™ DBEF II also allows you to eliminate a diffuser sheet and thus provides multifunctionality.

      3M™ Dual Brightness Enhancement Film (DBEF) QV2 with Optically Clear Adhesive (OCA)

      3M™ DBEF-QV2 with adhesive film is a thin, multi-layer reflective polarizer designed to be laminated to the rear polariser of an LCD panel to maximise brightness while reducing the risk of warping at higher temperatures. LCD panel efficiency is improved by reducing the amount of light normally absorbed by the panel polariser.

      3M™ DBEF QV2 with adhesive allows one polarisation of light to pass and the other reflected light is recycled in the backlight to boost display performance, increase end user viewing experience by improving front of the screen performance, and reducing the energy required to drive the backlight.

  • A medical professional pointing at a large screen showing medical results.

    • 3M™ Brightness Enhancement Film

      3M™ BEF is a prismatic film that manages the angular output of light from the backlight and uses refraction to compress the backlights output towards an on-axis viewer. 3M™ BEF films can be used as single sheets or as two sheets crossed at 90° to each other and is available in different configurations that can be useful for your specific application needs. 3M™ BEF can also be used in conjunction with 3M™ DBEF and 3M™ ESR.

      3M™ Enhanced Specular Reflector (ESR)

      3M™ Enhanced Specular Reflector (ESR) is a thin film, 100% polymer reflector. 3M™ ESR is used as the backlight reflector for LCD's and provides ›98% reflectance, across the entire visible spectrum, to maximise the recycling efficiency of backlights for your LCD's. 3M™ ESR can be used in conjunction with 3M™ BEF and 3M™ DBEF.

Protection films

Protection films

3M™ Protection Films help protect displays against damage that can occur from the rigors of everyday use. These films provide protection against moisture ingress in sensitive displays as well as glare and scratch protection. Compatible with optically clear adhesives and pressure sensitive adhesives.

  • Grocery store barcodes with 3M™ Barrier Films on them.
    3M™ Barrier Films

    3M™ Barrier Films are designed to provide a barrier to water and oxygen transmission while maintaining the optical transmittance characteristics of the base films. These optically clear multilayer films are remarkably impermeable due to their construction consisting of a polyester substrate with a very thin barrier coating made of layers of polymer and oxide. These films are lighter, more impact resistant, and more flexible than glass.

  • Worker with a hard hat choosing something on his iPad in front of a factory in the background.
    3M™ Industrial Display Thermal Management Film

    3M™ Anti-Glare Filters are an exceptional solution for electronic displays in rugged environments, providing durable protection and improved viewing quality in a variety of lighting conditions.

Optically clear adhesives

  • Two people in white lab coats and hair nets pointing at a small screen while they work.

    3M OCA comes in a variety of thicknesses to suit your needs. Choose 3M OCAs for touch screens, and when you’re bonding film and glass. It’s ideal for transparent graphic overlays, projection screens and other applications where an optically clear adhesive is necessary. Avionics and military displays often carry the 3M OCAs for reliability, quality and durability of design. LCD clarity, color neutrality and reliability is improved with 3M OCAs.

Advanced solutions for protection, light control and display enhancement

  • Person in a white hard hat holding a tablet and touching the screen.
    Visual privacy and compliance

    With personal information disclosure laws becoming more restrictive, protecting your confidential information is more critical than ever.

  • Person working on a machine display in the interior of a factory with machines.
    Enhanced viewability and extreme conditions

    Improve both the durability and the readability of display screens, providing a new solution for users working in a variety of extreme environments.
